Overview:
The Divimath Goggle is a professional-grade FPV headset built for pilots and integrators who require secure digital video, exceptional analogue reception, ultra-low latency, and flexible operation across multiple frequency bands.
For digital operation, the goggle supports encrypted Divimath video transmission with no additional latency, helping protect the video feed against unauthorised viewing. For analogue operation, its integrated high-sensitivity 5.8GHz receiver delivers industry-leading weak-signal reception without requiring an external module. The optional analogue Expansion Bay adds support for additional analogue frequency bands, including 3.3GHz.
A dedicated 3.5mm PPM input allows the goggles to receive channel commands from a compatible RC controller. This enables rapid, synchronised frequency hopping with encrypted Divimath digital video, conventional analogue video, and multi-band analogue systems operating across frequencies such as 5.8GHz and 3.3GHz.
The result is a single NDAA-compliant headset designed to support secure digital video, integrated 5.8GHz analogue, expanded analogue frequency coverage, and external HDMI video sources.
Features:
- Secure digital video: Supports encrypted Divimath digital video to help protect the video feed against unauthorised reception and viewing.
- No added encryption latency: Video encryption does not increase the system's ultra-low latency.
- Mission-focused operation: Designed for government, defence, commercial, and other applications where an openly viewable video feed is unacceptable.
- Ultra-low-latency digital video: Less than 3ms glass-to-glass latency, depending on the selected video mode.
- Encrypted frequency hopping: Rapid channel changes can be used while operating an encrypted Divimath digital video link.
- Built-in digital DVR: Record received Divimath digital video using the integrated H.264 DVR.
Industry-leading analogue video
- Integrated high-sensitivity 5.8GHz analogue receiver: Excellent weak-signal reception and clear analogue video without requiring an external receiver module.
- Optional analogue Expansion Bay: Add a compatible analogue receiver module for additional frequency bands, including 3.3GHz.
- Multi-band analogue operation: Use the integrated 5.8GHz receiver together with an expansion receiver for operation across multiple analogue frequency bands.
- Ultra-low-latency analogue processing: Less than 2ms latency through the integrated deinterlacer.
- Analogue DVR recording: Record received analogue video directly using the built-in H.264 DVR.
- Rapid analogue startup: Access the integrated analogue receiver within seconds of powering on the headset.
- Advanced analogue controls: Supports multiple analogue bands, automatic scanning, loop scanning, selectable aspect ratios, and configurable analogue display modes.
RC-Controlled rapid frequency hopping
- 3.5mm PPM control input: Connect the goggle to a compatible RC controller or transmitter using a 3.5mm PPM cable.
- Synchronised channel changes: The aircraft video transmitter and goggle receiver can follow the same RC switch command, keeping both ends of the video link on the selected channel.
- Encrypted digital frequency hopping: Rapidly change between configured Divimath digital channels while maintaining digital video encryption.
- Analogue frequency hopping: Rapidly change between configured analogue channels using the integrated receiver.
- Multi-band analogue hopping: Switch between frequency bands such as 5.8GHz and 3.3GHz when the optional analogue Expansion Bay and a compatible receiver module are installed.
- Flexible RC integration: Video channel selection can be assigned to a switch or other control on a compatible RC transmitter.
Frequency-hopping operation requires compatible aircraft-side video transmitter control, RC configuration, and supported receiver hardware. Multi-band analogue operation requires the optional analogue Expansion Bay and a compatible analogue receiver module.
Specification:
- Display: Dual OLED microdisplays
- Display resolution: 1920×1080 per display
- Display refresh rate: 90Hz
- Field of view: 46°
- IPD adjustment: 58-72mm
- Focus adjustment: +4 to -7 diopters
- Digital video modes: 1080p/30, 720p/60, 540p/90
- Digital video latency: <3ms glass-to-glass
- analogue video latency: <2ms
- HDMI input latency: <1ms
- Integrated analogue receiver: 5.8GHz
- analogue channel presets: 80 channels across 10 bands
- analogue display formats: 4:3 and 16:9
- HDMI input: Mini-HDMI, HDMI 1.4b
- HDMI output: Mini-HDMI, HDMI 1.3a
- AV connection: 3.5mm
- PPM connection: 3.5mm
- Power input: 7-25.2V
- Battery compatibility: 2-6S LiPo
- Weight: 300g
- Country of origin: Thailand
Included:
- 1x Divimath Goggles
- Accessories
