Overview:
The FrSky EX14 is an entry-level 24-channel transmitter built around FrSky’s ECOS operating system. It combines a simplified setup and programming experience with useful connectivity and expansion options, making it a practical choice for newcomers to RC as well as experienced pilots looking for a straightforward radio.
Its built-in 2.4GHz ISRM-L RF module supports both FrSky ACCST D16 and ACCESS receivers, with low-latency control and full telemetry support. For additional flexibility, a rear Lite-type external module bay allows compatible third-party RF modules to be fitted, extending receiver options beyond the built-in system.
The EX14 features an ergonomic case with rounded hand grips, smooth GM7 potentiometer gimbals and an easy-to-read backlit monochrome display. A selection of top-mounted switches and sliders, four trim controls, four programmable quick-access buttons and two rear momentary buttons provide plenty of options for controlling aircraft functions. USB-C charging for a 2S battery and wired trainer support via the DSC connection add further convenience.
Features:
- ECOS operating system: FrSky’s streamlined operating system offers a more accessible setup and programming experience, while retaining a familiar layout inspired by ETHOS.
- Integrated 2.4GHz RF system: Supports FrSky ACCST D16 and ACCESS receivers, with low-latency control and full telemetry functionality.
- External module expansion: A rear Lite-type module bay allows compatible external RF modules to be installed for additional receiver and protocol options.
- Ergonomic design: Rounded hand grips and a lightweight case provide a comfortable feel during extended flying sessions.
- GM7 gimbals: Potentiometer-based gimbals with an acrylic panel provide smooth, precise stick control.
- Versatile control layout: Top-mounted switches and sliders, four trims, four programmable quick-access buttons and two rear momentary buttons offer flexible control assignment.
- Wired trainer support: The DSC connection allows the transmitter to be used with a compatible wired training setup.
- USB-C charging: Supports charging a compatible 2S battery directly through the transmitter.
- Audible alerts: An integrated buzzer provides audible warning and notification signals.
- Optional stand compatibility: The rear design can accommodate an optional CNC aluminium stand for convenient hands-free positioning.
Specification:
- Model: FrSky EX14
- Operating system: ECOS
- Internal RF module: ISRM-L
- Operating frequency: 2.4GHz
- Maximum channels: 24
- Display: Backlit monochrome LCD
- Display resolution: 128x64 pixels
- Operating voltage: 6.5-8.4V
- Typical operating current: 100mA at 7.4V
- Battery compartment dimensions: 69.5x38.5x20mm
- USB charging input: 5V ±0.2V, minimum 2.0A
- Trainer connection: DSC
- Dimensions: 192x193x72mm (L × W × H)
- Weight: 550g (excluding battery)
- Operating temperature: -10°C to 60°C
Included:
- 1x FrSky EX14 2.4GHz Transmitter
- 1x Battery (pre-fitted)
