Overview:
The GEPRC Cinelog30 V2 WTFPV blends cinematic capability with recreational flying in a compact and durable 3″ frame. Built on a robust 2.5 mm carbon fibre chassis, it features ducted protection for both propellers and camera, resulting in stable and safer indoor flights. Its integrated TAKER F722 45 A AIO flight system and powerful 1404 KV3850 motors deliver responsive handling, while the flexible build options make it suitable for ading digital or analogue video setups.
The manufacturer estimates a flight time of around 8 minutes using a 720mAh 4S battery, with a plug-and-play assembly, this drone suits both cinewhoop pilots and freestyle flyers alike.
Features:
- Robust 2.5 mm carbon fibre ducted frame protects props and camera
- Protective prop guards reduce damage risk during collisions
- TAKER F722 45 A 32‑bit AIO flight controller simplifies wiring and mounting
- SpeedX2 1404 KV3850 brushless motors for agile thrust and precision
- Compatible with both digital and analogue FPV camera systems
- Rear USB port for quick Betaflight tuning and firmware updates
- Modular design allowing Naked GoPro, Action2 or Insta360 mounting
- Recommended take-off weight under 249 g with canopy and 4S battery for legal compliance
Specification:
- Model: GEPRC Cinelog30 V2 WTFPV
- Frame: GEP‑CL30 V2, 2.5 mm carbon fibre
- Wheelbase: 124 mm
- Flight controller: TAKER F722 45 A AIO (STM32F722RET6 MCU + ICM42688‑P gyro)
- ESC: 32‑bit 45 A, peak current rating included
- Motors: SpeedX2 1404 KV3850 brushless
- Propellers: HQProp DT76 mm tri‑blade V2
- Battery connector: XT30, supports 4S LiPo 660–720 mAh
- Receiver compatibility: PNP/ELRS 2.4 GHz/TBS NanoRX options
- Payload compatibility: Naked GoPro, Action2, Insta360 cameras
- Camera configuration variants: Analogue, Digital (HD O3)
Available Versions (See below for purchase options):
- GEPRC Cinelog30 V2 WTFPV PNP
- GEPRC Cinelog30 V2 WTFPV ELRS
Included:
- 1x GEPRC Cinelog30 V2 WTFPV Drone
- Accessories
