GEPRC EM2812 900KV Brushless Motor

Overview:
The GEPRC EM2812 900KV Motor is a brushless motor ideal for 6S powered quads. Developed as part of GEPRC’s EM series, it combines a large 2812 stator size with a 900KV winding to deliver strong low-end torque and efficient propeller control for long-range and heavier cinematic platforms.

Its high-torque magnetic circuit design and reinforced M5 steel shaft help maintain stability and durability under sustained load, while the 19x19mm mounting pattern provides compatibility with a wide range of larger FPV frames. The motor also uses high-quality NSK/NMB bearings and N52H magnets for smooth operation and reliable performance across extended flights.

Features:
- Optimised for 6S long-range and cinematic configurations
- High-torque magnetic circuit design for improved propeller control
- High-strength M5 steel shaft for increased durability
- NSK/NMB bearings for smooth and reliable operation
- N52H curved magnets
- 19x19mm mounting pattern compatible with larger FPV frames
- Single strand copper winding construction
- Designed for 7-9" FPV drone builds

Specification:
- Model: EM2812 900KV Motor
- KV rating: 900KV
- Stator size: 2812
- Configuration: 12N14P
- Input voltage: 25.2V (6S LiPo)
- Recommended propeller size: 7-9 inch
- Maximum power: 1010W
- Peak current: 46A
- Interphase resistance: 43mΩ
- Shaft diameter: 5mm
- Shaft protruding length: 16mm
- Motor dimensions: 33x26.1mm
- Mounting holes: 19x19mm
- Lead length: 260mm
- Wire gauge: 18AWG
- Recommended ESC: 50A-60A
- Weight: 76g

Included:
- 1x EM2812 900KV Motor
- Accessories
