GEPRC Vapor-X6 HD Freestyle 6" FPV (ELRS)
GEPRC Vapor-X6 HD Freestyle FPV Drone available in two options, fitted with either an Analogue Camera or DJI O3.
Overview:
The GEPRC Vapor‑X6 is a high‑performance 6-inch, 6S freestyle FPV drone designed for pilots demanding a blend of raw power, stability, and crystal‑clear video. With a 254.5 mm wheelbase and rugged 5mm carbon‑fibre arms, it delivers both agility and resilience. Equipped with the GEP‑F722‑HD V2 flight controller, 60 A BLHeli_S ESC, GEPRC SpeedX2 2407E KV1750 motors, this ready‑to‑fly package offers seamless integration for both stunning footage and responsive freestyle flying.
Features:
- Robust 5 mm carbon‑fibre arms ensure resilience during aggressive manoeuvres or crashes
- Integrated aluminium camera protector reduces vibration and shields against impact
- Taker 60 A BLHeli_S 4‑in‑1 ESC delivers smooth and reliable power distribution
- GEP‑F722‑HD V2 flight controller with SPI‑connected ICM42688‑P gyro and black‑box storage
- ELRS 2.4 GHz for secure, low-latency control
- Field‑tuneable via rear USB port, simplifying in-situ adjustments
Specification:
- Model: GEPRC Vapor-X6 HD Freestyle FPV Drone
- Wheelbase: 254.5mm
- Arm Thickness: 5mm
- Flight Controller: GEP‑F722‑HD V2 with STM32F722 MCU, ICM42688‑P gyro, BMP280 barometer, 16 MB black‑box
- ESC: Taker H60_BLS 60 A BLHeli_S 4‑in‑1
- Motors: GEPRC SpeedX2 2407E KV1750
- Propellers: HQProp 6x3.5x3
- VTX: DJI O3 Air Unit (analogue 5.8GHz variant optional)
- Battery Connector: XT60
- Recommended battery: 6S LiPo 1500-2200mAh
- Typical Take-Off Weight (PNP): 453g
- Manufacturer estimated flight time: 14-19 minutes (dependent on flight style and battery used).
Available Versions (See below for purchase options):
- GEPRC Vapor-X6 HD O3 FPV Drone (ELRS)
- GEPRC Vapor-X6 HD Analog FPV Drone (ELRS)
Included:
- 1x GEPRC Vapor-X6 HD Freestyle FPV Drone
- Accessories
