Overview:
The HappyModel M8 Freestyle HD ELRS V3.0 is an agile, ready-to-fly micro drone that introduces serious ability and video performance in a compact package. As the latest Freestyle edition featuring ExpressLRS V3, it offers pilots a powerful yet lightweight 2S digital FPV platform. With a responsive HDZero AIO15 flight controller, swift RS1102 13500KV motors, and efficient HQPROP 45mm props, the M8 delivers exceptional control and smooth performance both indoors and outdoors. Weighing just 33.5g, it excels in speed and manoeuvrability, while retaining the portability of a micro whoop.
Features:
- Compatible with HDZero Goggles
- ExpressLRS V3 receiver integrated into the HDZero AIO15 flight controller for low-latency control
- Dual-rate HDZero VTX with selectable 25mW and 200mW outputs
- RS1102 13500KV brushless motors for high-speed thrust
- HQPROP 45mm tri-blade propellers, optimised for freestyle agility
- Lightweight overall weight of 33.5g preserving nimble flight characteristics
- 2S battery compatible, supporting 550mAh for extended flight performance
- Pre‑flashed with Bluejay ESC firmware and Betaflight preset
- Plug‑and‑play configuration with canopy, spare parts, and tools included
Specifications:
- Model: Happymodel Mobula 8 Freestyle HD
- Wheelbase: 80mm
- Weight: 33.5g
- Flight controller: HDZero AIO15, featuring STM32G473 MCU and ICM42688 gyro
- ESC: 4‑in‑1 15 A BLHeli_S with Bluejay firmware
- Receiver: SPI-connected ExpressLRS 2.4 GHz V3.0
- Video transmitter: HDZero integrated, 25mW/200 mW output
- Motors: RS1102 KV13500, 9‑pole 12‑slot, 2mm stator length
- Propellers: HQPROP 45 mm tri-blade (~0.33g each)
- Battery input: 2S LiPo/LiHV, recommended 550 mAh
- Flight controller board size: 31.3x31.3mm with 25.5mm mounting holes
Included:
- 1x Happymodel Mobula 8 Freestyle HD EELRS v3.0
- Accessories
