Overview:
The Hobbywing LED Program Card provides a quick and convenient way to configure compatible Hobbywing brushless aircraft ESCs without navigating transmitter programming menus. Its simple push-button operation and clear LED display allow pilots to adjust ESC settings in seconds, making it an ideal accessory for anyone regularly setting up or fine-tuning their power system.
Compact enough to keep in your flight box, the Program Card is particularly useful when experimenting with different aircraft or setups, allowing programming changes to be made out in the field with minimal effort. Compatible settings vary depending on the ESC model, but commonly include brake mode, battery type, low-voltage cut-off, timing, start mode and throttle response.
Designed specifically for Hobbywing aircraft ESCs, the LED Program Card is compatible with the SkyWalker, FlyFun, Guard and Sword series of brushless ESCs. It connects directly to the ESC's programming lead and is powered by the ESC's BEC. If the ESC does not provide a BEC output, the card can also be powered from an external 4.8-6.0V supply.
Features:
- Quickly programmes compatible Hobbywing aircraft ESCs.
- Simple push-button operation with an easy-to-read LED display.
- Faster and more convenient than transmitter-based programming.
- Compact and lightweight design, ideal for field use.
- Allows rapid adjustment of supported ESC parameters.
- Connects directly to the ESC programming port.
- No computer or additional software required.
Specification:
- Compatible Hobbywing Series ESCs: SkyWalker, FlyFun, Guard (discontinued), Hobbywing Sword (discontinued)
- Not compatible with: Hobbywing Platinum series ESCs
- Operating voltage: 4.8-6.0V DC
- Power source: ESC BEC or external 4.8-6.0V battery (when required)
- Dimensions: 88×58×14mm
- Weight: 40g
Included:
- 1x Hobbywing LED ESC Program Card
- 1x Programming Cable
- Label stickers
