Overview:
The MATEN 5.8G 2.5W VTX PRO is a high-power video transmitter, newly developed by the GEPRC team. Delivering outstanding performance, it offers five adjustable power levels with a maximum output of 2500mW. Its transmission signal is exceptionally stable with excellent penetration capability.
It features a high-strength CNC-machined aluminium alloy casing to aid heat dissipation. Its distinctive exterior design, combined with active fan cooling, enhances impact resistance and provides superior thermal management. It supports the IRC Tramp protocol, enabling rapid parameter adjustment via OSD. The built-in microphone transmits live audio from the FPV drone in real time.
Features:
- Five levels of adjustable power, up to 2500mW, suitable for long distance flight
- High strength aluminum alloy CNC shell, with auxiliary heat dissipation
- The built-in micro turbo fan actively dissipates heat
- Wide voltage input, supports 7-36V input.
- One function button, three indicator lights, making the unit easy to control.
- VTX control protocol- IRC Tramp, supports OSD parameter adjustment.
- High Temperature control protection function
- VTX with built in microphone, Real-time transmission of Drone’s sounds.
- 72 transmission channels
- Supports 20x20mm(M2) and 30.5×30.5mm(M2) installation hole position
Specification:
- Model: GEPRC MATEN 5.8G VTX PRO (GP106448)
- Size: 36.3×36.3×15.1mm
- Mounting hole: 20x20mm(M2),30.5×30.5mm(M2)
- Output power: 25mW/200mW/600mW/1600mW/2500mW/Pit mode
- Frequency: 5.8G
- Channel: 72CH
- Input voltage: DC7-36V（2-8S Battery）
- Output voltage: 5V@600mA
- Protocol: IRC Tramp
- Antenna interface: MMCX
- Cable interface: SH1.0 6pin
- Video format: PAL/NTSC
- Microphone: Built in microphone
- Weight: 20g
Included:
- 1x GEPRC MATEN 5.8G VTX PRO
