Overview:
The SkyRC D750 MIX AC/DC charger is a high-power dual-channel charger designed for demanding RC applications where performance, flexibility and efficiency are essential. With both AC and DC input support, it delivers up to 500W on AC and 1600W on DC, making it suitable for everything from home charging setups to high-output field use.
Built around a dual independent output design, the D750 MIX allows two batteries to be charged simultaneously with separate control over each channel. This makes it ideal for users running multiple packs across drones, RC cars, aircraft or boats. With support for up to 8S LiPo batteries and charge currents up to 32A per channel, it is capable of handling both small packs and large, high-capacity batteries with ease.
A key advantage of the D750 MIX is its reverse discharge capability, which allows energy to be transferred between batteries rather than wasted as heat, improving efficiency when cycling packs. In addition, the charger can function as a fully adjustable DC power supply, providing controlled voltage and current output for powering equipment, testing electronics or setting up RC systems.
The interface features a modern colour display with a clear, intuitive layout, while Bluetooth connectivity enables control and monitoring via the SkyRC mobile app. Combined with wide chemistry support and high output capability, the D750 MIX is designed for users who need a powerful, versatile charging solution for a range of RC applications.
Features:
- Dual independent charging channels for simultaneous battery management
- AC and DC input for flexible use at home or in the field
- High output capability for fast charging of large capacity packs
- Supports a wide range of battery chemistries including LiPo, LiHV, LiFe, Li-ion, NiMH, NiCd and Pb
- Reverse discharge function to transfer energy between batteries efficiently
- Adjustable DC power supply mode for powering RC equipment and electronics
- Parallel charging capability for increased charging speed
- Bluetooth connectivity for app control and monitoring
- USB-C PD output for charging external devices
- Colour display with intuitive, modern interface
Specification:
- Model: SkyRC D750 MIX AC/DC Dual Channel Smart Charger
- Input voltage: AC100–240V / DC9–49V
- Charge power:
- AC: 500W total
- DC: 1600W total (1100W single channel)
- Charge current:
- LiPo/LiFe/Li-ion/LiHV (2–8S): 0.1–32.0A
- LiPo/LiFe/Li-ion/LiHV (1S) / NiMH/NiCd: 0.1–10.0A
- Pb: 0.1–15.0A
- Parallel charge current: 33–50A
- Discharge current: 0.1–4.0A
- External discharge current: 0.5–40A (with external discharger)
- Discharge power:
- Main port: 45W
- Balance port: up to 20W (LiPo/8S)
- Reverse discharge: up to 1100W
- Balance current: max.1.9A
- Supported battery types:
- LiPo/LiFe/Li-ion/LiHV: 1–8S
- NiMH/NiCd: 1–20S
- Pb: 3S/6S/12S
- USB-C output: PD3.0 up to 20W (5V/9V/12V)
- DC power supply output: 5–36V / 0.3–32A
- Dimensions: 180x136x112mm
- Weight: 1626g
Included:
- 1x SkyRC D750 MIX AC/DC Dual Channel Smart Charger
- 1x UK AC Mains Plug
