Sub250 Nanofly20 2S 2" HD O4 FPV Drone ELRS

Overview:
The Sub250 Nanofly20 2S HD O4 is a more powerful evolution of the Nanofly platform, designed for outdoor micro-freestyle flying with increased thrust and HD quality video. Retaining the compact 88mm wheelbase, this version introduces a strong frame design and improved components to handle the demands of a 2S power system.

Compared to the 1S version, this 2S model features 1002 14000KV motors and a 12A AIO flight controller, delivering more power for improved control. This makes it well-suited to more aggressive freestyle manoeuvres.

The key feature of this version is the DJI O4 digital system, providing high-definition video transmission with onboard recording capability. This allows pilots to capture clear HD footage directly from the drone while maintaining a compact and lightweight setup.

The frame has a resilient 2mm carbon main plate and extended edge protection, improving durability and helping protect motors during minor impacts. Combined with the increased power of a 2S setup, this makes the Nanofly20 2S HD O4 a capable micro platform for outdoor freestyle and cinematic flying in tighter environments.

Features:
- DJI O4 digital system with high-definition video and onboard recording
- Increased power output compared with 1S version for improved thrust/power
- 12A AIO flight controller with integrated ELRS receiver
- Reinforced carbon frame with increased thickness for durability

Specification:
- Wheelbase: 88mm
- Frame: NF2S carbon fibre
- Arm thickness: 2mm
- Weight: 43g (without battery)
- Flight controller: Redfox A2 12A AIO
- MCU: STM32F411
- Gyro: BMI270
- ESC: Integrated 12A 4-in-1
- Propellers: HQProp 2X1X3LG-1.5MM-PC
- Motor: Sub250 1002 14000KV
- Video system: DJI O4 Air Unit
- Receiver: ELRS 2.4GHz (onboard)
- Recommended 2S battery: 450–550mAh (Not included). See batteries and charger in Related Products at the bottom of this page.
- Battery bay dimensions: (w)18x(h)12.7mm (Length not restricted)
- Battery connector: XT30
- Goggles compatibility: DJI Goggles N3, DJI Goggles 3

Included:
- Sub250 Nanofly20 2S HD O4 Micro FPV Drone (ELRS)
- Spare Props
- Accessories/Spares
