T-Motor AS2317 880KV Fixed Wing Motor

The T-Motor AS2317 is a fixed wing motor, 880KV with long shaft.
Manufacturer: T-Motor
Availability: In stock
£17.54 inc VAT
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Overview:

The T-Motor AS2317 is a motor designed for Fixed Wing models. The AS series is T-Motors value range, but still retains a very high end finish.

This version comes with a long shaft and is 880KV.

Specifications:

- KV: 880KV Long Shaft
- Configuration: 12N14P
- Shaft Diameter: 4mm
- AWG: 20#
- Cable length: 100mm
- Internal Resistance: 80mΩ
- Motor Dimensions (Dia.*Len): Φ29.4×52mm
- Weight with wires(g): 81g
- ldle current@10v(A): 0.74A
- No.of Cells(Lipo): 3-4S
- Peak Current: 26A
- Prop recommendation 10x5.5 (4S) / 11x5.5 (4S) / 12x6 (3S) / 13x8 (3S)

Includes:

- 1x T-Motor AS2317 880KV Long Shaft Fixed Wing Motor
- Mounting Screws, prop adapter & Lock Nut
