Overview:
The T-Motor F90 2806.5 is a high-torque brushless motor designed specifically for long-range, cinematic and heavy-duty FPV drone builds. With a large 2806.5 stator, it delivers strong torque and efficient power output, making it particularly well suited to drones using larger propellers where smooth throttle control and sustained efficiency are essential for extended flight times.
Developed for modern long-range FPV platforms, the motor is capable of driving 6–8inch propellers efficiently while maintaining stable performance under load. The larger stator volume improves torque compared with smaller motors, allowing the F90 to spin larger propellers with lower RPM while maintaining strong thrust and efficiency. This makes it a popular choice for long-range cruisers, cinematic rigs and heavier freestyle builds where reliable power delivery is required.
The F90 series is available in three KV options - allowing builders to tailor the motor to their aircraft configuration and performance aim. Lower KV variants such as 1300KV are typically used on larger 7–8inch propeller setups for maximum efficiency and endurance, while higher KV options such as 1950KV provide faster throttle response and stronger thrust for smaller propellers or more aggressive flying styles.
Constructed using precision machining and high-quality materials, the F90 combines durability with smooth motor performance. Its design prioritises stable operation, efficient energy use and strong thrust output, making it well-suited to pilots building reliable long-range or cinematic FPV drones.
Features:
- Designed for long-range, cinematic and heavy-lift FPV drones
- Large 2806.5 stator size delivers strong torque for efficient propulsion
- Suitable for 6inch to 8inch propeller builds, depending on KV and setup
- Optimised for smooth throttle response and efficient cruising performance
- High-power motor design capable of driving larger propellers with stable output
- Durable construction designed for demanding long-range and freestyle applications
Specification:
- Model: T-Motor F90 2806.5 Brushless Motors
- Stator configuration: 12N14P
- Motor dimensions: Ø33.4x34.7mm
- Recommended voltage: 5–6S LiPo
- Shaft diameter: 4mm
- Mounting pattern: 19x19mm (M3)
- Lead wire: 20AWG, approx.230mm
- Weight: approx.46.6g (with wires)
- Performance data (depending on KV variant):
- Peak current (60s): up to 53.6A
- Maximum power (60s): up to 1302W
- Idle current (10V): approx.0.95–1.5A
- Internal resistance: approx.45–76mΩ
Available versions (see below for purchase options):
- T-Motor F90 1300KV Motor
- T-Motor F90 1500KV Motor
Included:
- 1x T-Motor F90 Brushless Motor
- Accessories
