Overview:
The T-Motor (AKA 'T-Hobby') Velox F7 SE Flight Controller is packed with advanced features, including built-in Bluetooth connectivity, dual BECs, support for both HD and analogue video systems, compatibility with up to eight motors, PIT mode, selectable voltage outputs, and a generous 128Mbit black box for flight data recording. A built-in barometer provides accurate altitude sensing, while Bluetooth connectivity allows parameters to be adjusted wirelessly via the SpeedyBee app on a mobile phone, removing the need for a computer when configuring the quad in the field.
The flight controller follows the latest Betaflight wiring standard and uses unified connector layouts to reduce the risk of incorrect connections and potential hardware damage.
T-Motor’s second-generation design delivers smooth and stable flight performance by suppressing electrical noise by up to 90dB, resulting in a clean, low-latency gyroscope signal. The Velox F7 SE also features voltage-selectable pads, making it easy to supply the correct voltage to your VTX and camera without the need for awkward or cross-board wiring.
At its core, the Velox F7 SE is powered by a high-performance STM32F722 MCU, paired with an ICM-42688-P (SPI) gyroscope for precise and responsive control. The board provides six UARTs, a USB Type-C port, and full support for both AT7456E analogue FPV systems and HD digital VTX setups.
Specifications:
- Model: VELOX F7 SE (AFV01030009)
- MCU: STM32F722
- Gyroscope: ICM-42688-P(SPI)
- BEC: 5V2A & 10V1.5A
- Uarts: 6
- Bluetooth TMFC
- OSD AT7456E&HD
- Black box: 128MB
- USB: Type-C
- Weight: 9g
- Size: 37.5*40*6.4mm
- Installation hole: 30.5*30.5/φ4mm
- Input voltage: 12-27V(3-6S)
Includes:
- T-Motor Velox F7 SE Flight Controller
- Accessories
