Overview:
The Team BlackSheep M10N GPS module is a compact, high-precision navigation unit designed for FPV drones and fixed-wing aircraft. Built around the advanced u-blox M10 chip, it delivers exceptional satellite reception, faster positional lock times, and improved accuracy compared to previous generations. Supporting both GPS and GLONASS satellite systems, the M10N offers greater stability and reliability, even in challenging environments.

Its lightweight, durable design makes it ideal for a wide range of builds, from small racing drones to long-range aircraft. The module features a ceramic patch antenna for optimal signal sensitivity and comes pre-wired with a standard 6-pin connector for easy installation with popular flight controllers such as those using Betaflight or iNav.

The TBS M10N GPS provides accurate latitude, longitude, altitude, and ground speed data for use with features like GPS rescue, return-to-home (RTH), and on-screen display telemetry. Engineered by Team BlackSheep for performance and reliability, it’s the perfect choice for pilots demanding consistent and precise navigation data in all conditions.

Features:
- High-performance u-blox M10 GNSS chip supporting GPS, GLONASS, and Galileo
- Fast satellite acquisition and improved positional accuracy
- Compact, lightweight module ideal for racing and freestyle drones
- Ceramic patch antenna for superior signal reception
- Pre-configured and plug-and-play with most FCs supporting UART GPS input
Integrated EEPROM retains settings between power cycles
- Compatible with Betaflight, iNav, and other major flight control firmware
- Supports GPS-based features including Rescue Mode, RTH, and telemetry overlay

Specification:
- Receiver Type: GPS L1 C/A, QZSS L1 C/A/S, BDS B1I/B1C, Galileo E1B/C, SBAS L1 C/A (WAAS, EGNOS, MSAS, GAGAN)
- Default Position System: GPS, BDS, GALILEO
- Augmentation System: SBAS, QZSS
- Chipset: u-blox M10 series
- Antenna Type: Ceramic patch
- Communication Interface: UART (TX/RX)
- Baud Rate: 4800–921600bps (default: 115200 bps)
- Input Voltage: 3.6V – 5.5V (typical: 5.0V)
- Cold Start Time: <26s
- Warm Start Time: <2s
- Update Rate: 0.25–18Hz (default: 10Hz)
- Retained Settings: Non-volatile EEPROM storage
- Module Dimensions:  16.5×12.3×6mm
- Weight: Approx. 3g

Included:
- 1x Team Black Sheep M10N GPS Glonass
- Accessories
