Caddx Walksnail Ascent HD Goggles

Overview:
The Caddx Walksnail Ascent Goggles are an affordable digital FPV viewing system designed for pilots who want to move beyond analogue video and experience high-definition flying. Built around the Walksnail Ascent HD system, they combine a large integrated display, onboard video reception and digital video recording in a box-style goggle.

The 4.5-inch Full HD LCD provides a clear view of the live feed, with an average video latency of approximately 32ms for responsive control. The integrated receiver uses built-in directional antennas to maintain the video link, while the onboard DVR records footage directly to a microSD card (not supplied) for playback and review. The goggles also support compatible prescription lens inserts (available separately), helping pilots tailor the viewing experience to their eyesight.

Designed for simplicity, the Ascent Goggles suit both beginners and experienced pilots looking for a straightforward digital FPV setup. They work with compatible Walksnail Ascent transmitters, including the Ascent Lite System, but are not compatible with the Walksnail Avatar system. The goggles can be powered from a 2-6S LiPo battery (sold separately).

Features:
- Integrated digital receiver: Receives compatible Ascent HD video without requiring a separate receiver module.
- Built-in DVR: Records flights to a microSD card (not supplied) for playing back your best flights.
- Integrated directional high-gain antennas to create a compact design with a stable video connection.
- Customisable lens options: Compatible with suitable prescription and blue-light-filter lens inserts which are available separately.
- Onboard playback and controls: Navigate menus, manage recordings and adjust display settings directly from the headset.
- Straightforward setup: A practical option for pilots entering digital FPV or building an Ascent-based ecosystem.

Specification:
- Model: Caddx Walksnail Ascent Goggles
- Video system: Ascent HD
- Display type: LCD
- Screen size: 4.5"
- Screen resolution and refresh rate: 1920x1080 at 60Hz
- Field of view: 58°
- Supported transmission resolutions: 1080p@60fps and 720p@60fps
- Maximum video bitrate: 25Mbps
- Average latency: Approximately 32ms
- Operating frequency: 5738.5-5806.5MHz
- Channels: 4, according to the manufacturer's current product listing
- Antenna gain: 4.9dBi
- Antenna polarisation: LHCP
- Advertised transmission range: Over 4km under suitable conditions
- Power input: 6 - 25.2V DC (2–6S)
- Power connector: DC 5.5 × 2.1mm
- DVR Storage: microSD card (not supplied), up to 256GB

Included:
- 1x Caddx Walksnail Ascent HD Goggles
- Accessories
