Happymodel Mobula6 2024 1S 65mm Whoop (ELRS)

Happymodel Mobula6 2024 1S 65mm Whoop (ELRS) receiver.
Manufacturer: Happymodel
Availability: In stock
£100.65 inc VAT
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Overview:
The Happymodel Mobula6 2024 1S 65mm Whoop (ELRS) with ultra-lightweight design and agile performance. The Mobula6 2024 edition features a 65mm wheelbase and weighs a mere 17.7 grams, making it exceptionally manoeuvrable for indoor flying.

Equipped with the SuperX ELRS AIO 5-IN-1 Flight controller, the Mobula6 2024 ensures responsive control and stable flight characteristics. The SE0702 KV28000 brushless motors provide smooth and powerful propulsion, suitable for both novice and experienced pilots.

The drone supports 1S Lipo/LIHV batteries, uses Gemfan 1208-3 31mm tri-blade propellers. The onboard 5.8G VTX and FX17-B 1/3 CMOS 800TVL camera offers adjustable transmitting power from 0 to 400mw with clear and vibrant footage.

Features:
- AIO Flight controller with serial ELRS Receiver and 5.8GHz Openvtx
- Super light 1S 65mm Brushless whoop only 17.7g
- Equipment with the lightest brushless motors-SE0702 only 1.46gram
- FX17-B 1/3 CMOS 800TVL Camera awesome footage
- Smooth and powerful
- Compatible for 1S Lipo/LIHV

Specifications:

- Brand Name: Happymodel
- Item Name: Mobula6 2024 1S 65mm ultra light micro FPV Whoop
- Wheelbase: 65mm
- Size: 81mm*81mm*37mm
- Weight: 17.7g
- V1.0/V2.0 version with SuperX ELRS V1.0 AIO

Motor
- Mode: SE0702 KV28000
- Configu-ration:9N12P
- Stator Diamter:7mm
- Stator Length:2mm
- Shaft Diameter:Φ1mm
- Motor Dimension(Dia.*Len):Φ9.5mm*14mm
- Weight(g):1.49g
- No.of Cells(Lipo):1S only

Propellers
- Materials: PC
- Inch: 31mm
- Pitch: 0.8 in
- Weight: 0.21g
- Mount hole diameter:  1mm

Flight controller
- SuperX ELRS AIO 5-IN-1 Flight controller
- MCU:STM32F411CEU6 (100MHZ, 512K FLASH) ,ESP32-PICO-D4
- Sensor:BMI270(SPI connection)
- Mount hole size: 25.5mm*25.5mm
- Power supply: 1S battery input (DC 2.9V-4.35V)
- Built-in 5A(each) Blheli_S 4in1 ESC
- Built-in Betaflight OSD(SPI Control)
- Built-in 5.8G OpenVTX 0mw~400mw (MSP control)
- Built-in UART ExpressLRS v3.0.0
- Built-in voltage meter sensor , voltage meter scale 110
- Built-in current meter sensor , current meter scale 1175

Onboard 4in1 ESC
- Power supply: 1-2S LiPo/LiPo HV

- Current: 12A continuous peak 15A (3 seconds)
- Support ESC-Configurator and BLHELI_S Suite configurator
- Factory firmware: Z-H-30 – Bluejay, 0.19, 48kHz
- Default protocol: DSHOT300

Onboard Serial ExpressLRS 2.4GHz Receiver
- RF Frequency: 2.4GHz

- Antenna: enameled copper wire 31mm length
- Telemetry output Power: <12dBm
- Receiver protocol: CRSF
- Default firmware version: ExpressLRS V3.0.1
- The same hardware with Happymodel EP1 receiver
- Could update firmware via ExpressLRS configurator or WIFI or Betaflight pass-through

Onboard 5.8g VTX
- Firmware version: OPENVTX
- MSP VTX
- PIT Mode support
- Channels:40ch
- Transmitting Power: 0/RCE/25mw/100mw/400mw
- Power supply: DC 5V
- Current (5v): <650ma (400mw)
- Antenna connector: U.FL

FX17-B Camera

- Model:FX17-B
- Image Sensor: 1/3″ CMOS
- Horizontal Resolution: 800TVL
- FOV 150°
- Signal System: NTSC
- Net Weight: 1.5g
- Dimensions: L14mm*W14mm*H13mm

Includes:

- Happymodel Mobula6 2024 1S 65mm Whoop (ELRS)
- Accessories
